Signal Isolator Frequency to DC Signal – ISM-12-1-1 (F)

Product Description :
ISM-12-1-1 (F) – Single input & Single output operating on 24VDC (18-36)VDC
Request to Quote
  • Accepts Frequency/Clock signal inputs and provides optically isolated proportional analogue output.
  • On site calibration facility-using ZERO/SPAN presets.
  • Operates on 24VDC (18-36) VDC.
  • Designed using ultra low drift components for long term stability.
  • Interface of low-level signals coming from the sensors or transducers from the plant to DCS, SCADA, PLC or PID process controllers without ground line interferences.
  • Signal multiplier – single input and 2 to 4 outputs.
ParametersDescription
InputClock Frequency of (0-1)KHz, (0-5)KHz, (0-10)KHz Frequency 2 DC levels of (5-24)vdc
RangeUser may specify the required temperature range (for RTD or T/C input). For other inputs, the required calibration range can be specified.
Output(4-20) mA, (0-5) VDC, (0-10) VDC,
For current output, RL (max.) = 500 Ohms.
For voltage output, RL (min) = 100K Ohms.
No. Of Outputs Maximum 4 parallel independent outputs can be provided for a single input.
Each output can be the same type or of a different type.
AccuracyAbsolute to the input.
CalibrationOn-site calibration facility through ZERO and SPAN presets accessible to the user.
IsolationInput and Output are optically isolated for DC inputs. The power supply is also isolated from Input and Output. (3-way isolation)
Isolation VoltageGreater than 1 KV.
Mounting35-mm. DIN rail mounting ABS enclosure.
SupplyDC Supply: 24VDC (18-36) VDC.
Size22 x 75 x 110
Sr. No.SpecificationsPart No.
Single Input and Single Output - ISM-12-1-1 (F)
1.1Input : (0-1)KHZ Output : 4-20mA2028-1-1
1.2
Input : (0-1)KHZ Output : 0-5V2028-1-2
1.3Input : (0-1)KHZ Output : 0-10V2028-1-3
1.4Input : (0-5)KHZ Output : 4-20mA2028-1-4
1.5Input : (0-5)KHZ Output : 0-5V2028-1-5
1.6Input : (0-5)KHZ Output : 0-10V2028-1-6
1.7Input : (0-10)KHZ Output : 4-20mA2028-1-7
1.8Input : (0-10)KHZ Output : 0-5V2028-1-8
1.9Input : (0-10)KHZ Output : 0-10V2028-1-9
